HFCN-9700+ LTCC High Pass Filter, 9700 - 16980 MHz
Features
• low cost
• small size
• temperature stable
• excellent power handling, 7W
• hermetically sealed
The Big Deal
• Small size 3.2mm x 1.6 mm
• High Power handling (7W)
• High rejection (30 dB typ)
• Ceramic construction
Applications
• electronic warfare (EW)
• sub-harmonic rejection
• transmitters/receivers
• lab use
Product Overview
New High Pass Filter HFCN-9700+ is an LTCC based filter, that extends the upper frequency cutoff range of
the existing HFCN series to 9.7 GHz. Systems that previously relied on large distributed filter elements to support these lower frequencies can save space and system complexity by integrating the HFCN-9700+ into new
designs. These filters are offered in a EIA 1206 package size and have a typical stop band rejection of 32 dB.
