    TC2-1T+    Surface Mount    RF Transformer    50Ω 3 to 300 MHz

Features

• good return loss

• excellent amplitude unbalance (0.5 dB typ)

and phase unbalance (4 deg. typ) in 1 dB bandwidth

• plastic base with leads

• aqueous washable

Applications

• impedance matching

• balanced to unbalanced transformation

• push-pull amplifier

Maximum Ratings

Operating Temperature -40°C to 85°C

Storage Temperature -55°C to 100°C

RF Power 0.25W

DC Current 30mA

Permanent damage may occur if any of these limits are exceeded.

Pin Connections

PRIMARY DOT         6

PRIMARY                4

SECONDARY DOT    1

SECONDARY           3

SECONDARY CT      2
